全自动凉茬机是能酒茬摊凉搅拌后，加入酒曲混合的设备。工作时间短、非常节约资源、自动加曲卸料、减轻了工人们的劳动强度，还杜绝了浪费粮食的现象。与粮食接触的部分均为的不锈钢材料。此外，该机在使用时输送、搅拌、下曲是均可变频调速的。

The full-automatic stubble cooler is a device that can add distiller's yeast for mixing after the stubble is cooled and stirred. Short working time, very saving resources, automatic bending and unloading, reducing the labor intensity of workers, and putting an end to the phenomenon of wasting food. The parts in contact with grain are made of high-quality stainless steel. In addition, the machine can be used for conveying, mixing and bending with variable frequency speed regulation.

使用时，酒茬在传送带上通过，在打碎和搅拌的同时风机工作，迅速降温，冷却后的酒茬在下料装置中与酒曲自动混合均匀。本实用新型全自动凉茬机提高了冷却效果、降低了功耗，了现有设备自积堵塞现象，并实现了酒茬和酒曲的自动混合。

When in use, the wine stubble passes through the conveyor belt, and the fan works while breaking and mixing to quickly cool down. The cooled wine stubble is automatically mixed with the starter in the blanking device. The full-automatic stubble cooler of the utility model improves the cooling effect, reduces the power consumption, solves the self accumulation and blockage of the existing equipment, and realizes the automatic mixing of wine stubble and koji.

在启动全自动凉茬机机之前，我们应当先检查机器的电机是否正常，再去启动设备。在检查时，应同时使用吹风机对电机内的灰尘等污垢杂物清理干净，还要测量接线是否合格，如果发现电机出现机械损伤或者火花灼痕应当立即进行必要的处理工作。

Before starting the automatic stubble cooler, we should first check whether the motor of the machine is normal, and then start the equipment. During the inspection, the blower shall be used to clean the dirt and sundries in the motor at the same time, and the wiring shall be measured to see whether it is qualified. If the motor is found to have mechanical damage or spark burn marks, necessary treatment shall be carried out immediately.

全自动凉茬机电机使用前的检查方法

Inspection method for motor of automatic stubble cooler before use

1、用压缩空气或手动吹风机吹净电动机内部灰尘、电刷粉末等，污垢杂物。

1. Blow the dust and brush powder inside the motor with compressed air or manual blower to remove dirt and sundries.

2、拆除与电动机连接的一切接线，用绝缘电阻表测量绕组对机座的绝缘电阻。若小于0．5MΩ时，应进行烘干处理，测量合格后再将拆除的接线恢复。

2. Remove all wiring connected to the motor, and measure the insulation resistance of the winding to the base with an insulation resistance meter. If it is less than 0.5m Ω, it shall be dried, and the removed wiring shall be restored after the measurement is qualified.

3、检查凉全自动凉茬机换向器的表面是否光洁，如发现有机械损伤或火花灼痕应进行必要的处理。

3. Check whether the surface of the commutator of the full-automatic stubble cooler is smooth and clean. If mechanical damage or spark burn marks are found, necessary treatment shall be carried out.

4、检查电刷是否严重损坏，刷架的压力是否适当，刷架的位置是否位于标记的位置。

4. Check whether the brush is seriously damaged, whether the pressure of the brush holder is appropriate, and whether the position of the brush holder is at the marked position.

全自动晾茬机亲民，根据全自动凉茬机电动机铭牌检查直流电动机各绕组之间的接线方式是否正确，电动机额定电压与电源电压是否相符，电动机的起动设备是否符合要求，是否完好无损。

The price of the full-automatic stubble dryer is close to the people. According to the nameplate of the motor of the full-automatic stubble cooler, check whether the wiring mode between the windings of the DC motor is correct, whether the rated voltage of the motor is consistent with the power supply voltage, and whether the starting equipment of the motor meets the requirements and is intact.

以上就是问题解答的相关内容了，希望能够帮助到大家，如对这一问题还存在任何疑问，都欢迎关注我们网站http://www.qfrtrq.com并咨询我们的工作人员，将竭诚为您服务。

The above is the relevant content of the question answer. I hope it can help you. If you still have any questions about this problem, you are welcome to follow our website http://www.qfrtrq.com And consult our staff, will serve you wholeheartedly.
