Stainless steel inner liner solid wood barrel can be said to be an excellent cost-effective wine storage container. Its inner liner is the key to wine storage. Choosing stainless steel as inner liner material can effectively prevent the volatilization of wine products, while ensuring the taste and purity of wine products. In addition, there is a layer of solid wood outside, which not only adds some features to its appearance, but also provides good protection for its inner gallbladder. Then let's talk about its configuration requirements.

　　不锈钢内胆实木酒桶的配置要求：

　　Configuration requirements of stainless steel inner liner solid wood barrel:

　　1、由于白酒是一种易挥发、易燃、易爆的介质，特别是贮存的基酒度数高，设计时要满足危险化学品容器设计需要，布局上要服从和满足消防设计要求，强度设计上要引用/T4735钢制焊接常压容器设计准则，选用焊接系数应不大于0.7。对特殊地理环境和地质构造上建设的白酒企业，设计上要充分考虑台风和地震等自然灾害的影响。

　　1. Because liquor is a volatile, flammable and explosive medium, especially the high degree of base liquor stored, the design should first meet the design needs of hazardous chemical containers, the layout should comply with and meet the fire safety design requirements, the strength design should refer to the design criteria of /T4735 steel welded atmospheric pressure vessels, and the welding coefficient should be less than 0.7. For liquor-making enterprises built in special geographical environment and geological structure, the influence of natural disasters such as typhoons and earthquakes should be fully considered in design.

　　2、材料使用上要选用钢板生产厂家的304系列钢板，并符合国标对板厚要求。钢板厚度严禁低于国标通用标准。并对材料进行适当的化学成分抽样检验。

　　2. In the use of materials, 304 series of high-quality steel plates from excellent steel plate manufacturers should be selected and meet the requirements of national standards for plate thickness. The thickness of steel plate is strictly prohibited to be lower than the general national standard. The appropriate chemical composition of the material was sampled and tested.

　　3、制造上要采用钨极氩气保护焊，3mm以下的钢板焊接宜采用普瑞特公司的水焊接法，并保证焊缝饱满焊透，焊接过程中注意焊接接头的相位变化，必要时要做金相分析，保证焊缝成形后的内在质量，下封头和4mm以上钢板要采用双枪焊接法，保证焊缝饱满焊透。

　　3. Tungsten Argon shielded arc welding should be used in manufacturing. The water welding method of Pratt Company should be used for steel plate below 3mm, and the full penetration of the weld should be ensured. The phase change of the welded joint should be noticed in the welding process. Metallographic analysis should be done when necessary to ensure the internal quality of the weld after forming. Double gun welding method should be used for steel plate below the head and above 4mm to ensure the full penetration of the weld.

　　4、质量控制上，要突出白酒介质的特性，对焊缝和部位进行控制，对下封头所有焊缝和下筒体与下封头间的环焊缝必须进行100%的表探，表探合格后进行盛水试漏试验。（具体的相关内容请参考仁泰酒容器《为什么酒厂都喜欢用不锈钢储酒器？》的相关内容）

　　4. In quality control, we should highlight the characteristics of liquor medium, control the key welds and positions, and conduct 100% surface inspection on all welds of the lower head and the circumferential welds between the lower cylinder and the lower head, and conduct leak test after the surface inspection is qualified. (For details, please refer to Rentai Wine Container Why Winery prefer stainless steel wine storage? 》 Relevant content)


　　5、由于白酒生产工艺中经常使用活性炭对白酒进行澄清处理，去除酒体中的异杂味，而活性炭的成份中含有大量的氯离子，处理过程中，活性炭会附于罐底，氯离子会对不锈钢产生腐蚀，形成所谓的“点状”锈蚀，影响容器的使用寿命。因此，在生产使用过程中，要勤清理活性炭附着物，也可在此类罐底部涂附环氧树脂，隔离活性炭中氯离子对不锈钢的侵蚀。

　　5. Activated carbon is often used in liquor production process to clarify liquor and remove odors in liquor. Activated carbon contains a lot of chloride ions. Activated carbon will be attached to the bottom of the tank during the process of liquor production. Chloride ions will corrode stainless steel, forming so-called "dot" corrosion, affecting the service life of the container. Therefore, in the process of production and use, it is necessary to diligently clean up the attachment of activated carbon. Epoxy resin can also be coated on the bottom of such tanks to isolate the corrosion of stainless steel by chloride ions in activated carbon.

　　以上就是为您介绍的不锈钢内胆实木酒桶的配置要求，您学会了吗？另外在其外层加一层实木装置，还可以对其起到一个保护的作用，以免在运输的过程中造成磕碰，影响设备的质量。

　　Above is the configuration requirement of stainless steel inner tank solid wood barrel introduced to you. Have you learned it? In addition, adding a layer of solid wood device on its outer layer can also play a protective role, so as to avoid collision in the process of transportation and affect the quality of equipment.
