The automatic stubble cooling machine is composed of frame, fan, conveyor belt, beating stick, blanking device and discharge pipe. The machine processes the spreading and drying, adding pulp, adding koji, mixing and discharging at one time. Compared with the traditional process, it greatly reduces the labor intensity and realizes automatic production. The automatic stubble cooler improves the cooling effect, reduces the power consumption, and solves the self accumulation and blockage of the previous equipment. It is an ideal cooling equipment.

全自动凉茬机的组成部分

Components of automatic stubble cooling machine

1.主要由机架、风机、传送带依次连接于传送带上的搅笼、打料棍、翻料棍、下料装置、出料管组成.

1. It is mainly composed of frame, fan, conveyor belt, mixing cage, beating stick, turning stick, blanking device and discharge pipe connected to the conveyor belt in turn

2.风机固定在传送带侧端的机架上并少设置为三台，所述的下料装置由下料斗和固接于下料斗下部的下料辊组成，所述的机架上设有高于传送带输送线两边的挡板。

2. The fan is fixed on the frame at the side end of the conveyor belt and at least three fans are set. The blanking device is composed of a hopper and a blanking roller fixed at the lower part of the hopper, and the frame is provided with baffles higher than both sides of the conveyor line of the conveyor belt.

3.使用时，酒茬在传送带上通过，在打碎和搅拌的同时风机工作，酒糟凉茬机，迅速降温，冷却后的酒茬在下料装置中与酒曲自动混合均匀。

3. When in use, the stubble passes through the conveyor belt, the fan works while crushing and stirring, and the distiller's grains cooling machine cools down quickly, and the cooled stubble is mixed with distiller's yeast automatically and evenly in the blanking device.

4.实用新型全自动凉茬机提高了冷却效果、降低了功耗，了现有设备自积堵塞现象，并实现了酒茬和酒曲的自动混合。

4. The utility model automatic stubble cooling machine improves the cooling effect, reduces the power consumption, solves the self accumulation and blockage phenomenon of existing equipment, and realizes the automatic mixing of stubble and koji.

酿酒设备凉茬机电机使用前的检查方法

Inspection method for motor of stubble cooler of liquor making equipment before use

1、用压缩空气或手动吹风机吹净电动机内部灰尘、电刷粉末等，污垢杂物。

1. Use compressed air or manual blower to clean the dust and brush powder inside the motor to remove the dirt.

2、拆除与电动机连接的一切接线，用绝缘电阻表测量绕组对机座的绝缘电阻。若小于0．5MΩ时，应进行烘干处理，测量合格后再将拆除的接线恢复。

2. Remove all the wiring connected with the motor, and measure the insulation resistance of the winding to the base with an insulation resistance meter. If less than 0.5m Ω After the measurement is qualified, the removed wiring shall be restored.

3、检查凉茬机换向器的表面是否光洁，如发现有机械损伤或火花灼痕应进行必要的处理。

3. Check whether the surface of the commutator of the stubble cooler is smooth and clean. If any mechanical damage or spark burn mark is found, necessary treatment shall be carried out.

4、检查电刷是否严重损坏，刷架的压力是否适当，刷架的位置是否位于标记的位置。

4. Check whether the brush is seriously damaged, whether the pressure of the brush holder is appropriate, and whether the position of the brush holder is in the marked position.

5、根据凉茬机电动机铭牌检查直流电动机各绕组之间的接线方式是否正确，电动机额定电压与电源电压是否相符，凉茬机，电动机的起动设备是否符合要求，是否完好无损。

5. According to the motor name plate of the stubble cooler, check whether the wiring mode between the windings of the DC motor is correct, whether the rated voltage of the motor is consistent with the power supply voltage, whether the stubble cooler and the starting equipment of the motor meet the requirements, and whether they are intact.
