The paver is welded with 304 square drawing pipe and 304 wire drawing plate, with high strength, neat and beautiful appearance, no rust, easy maintenance and wiping; the internal air chamber is designed with direct drainage outlet and chain duct air chamber, which can be washed with water directly.

整机变频调速控制，自动加曲速度无级调节，出料口加红外温度传感器，自动控制凉糟温度，根据温度控制风机启停个数及风量大小，达到凉糟降温目的，并降耗。

The whole machine is controlled by frequency conversion and speed regulation, with stepless adjustment of automatic bending speed. Infrared temperature sensor is added at the discharge port to automatically control the temperature of slag. According to the temperature, the starting and stopping number of fans and the air volume are controlled to achieve the purpose of reducing the temperature of waste grains and energy saving.

主传动采用国产减速机和一级大模数齿轮传动，结构紧凑，输出力矩大，不易损坏；凉糟链条运行速度变频器控制，在0.5-2.6m/m范围内无级调整，满足凉糟机工艺要求；凉糟机出口安装有温度传感器，实时测控出糟温度并控制凉糟链条运行速度，保证摊晾效果；

The main drive adopts domestic famous brand reducer and first-class large modulus gear transmission, with compact structure, large output torque and is not easy to be damaged; the running speed of the cooling grain chain is controlled by frequency converter, which can be adjusted steplessly in the range of 0.5-2.6m/m to meet the process requirements of the distiller; a temperature sensor is installed at the outlet of the distiller to measure and control the temperature of the outlet in real time and control the running speed of the chain to ensure the spreading effect;

凉糟筛板用304不锈钢冲制成型，节距100，宽度1220，筛孔采用长条孔，无飞边毛刺，透气性好；筛板底部滚轮支撑，料斗下料时筛板不变形；

The screen plate is made of 304 stainless steel, the pitch is 100, the width is 1220, the sieve hole is long hole, no flash burr, good air permeability; the roller support at the bottom of the sieve plate, the sieve plate does not deform when the hopper is feeding;

采用三台或四台强力离心风机冷却酒糟，风机均可变频调速和工频运行，根据出口温度由电脑自动控制每台风机的开停变频运行和工频运行，配合两套翻渣辊对酒糟翻动,既减少耗能，又可保证酒糟摊晾效果；每个风机独立风室经优化设计，内部设计有专门结构，分层送风，保证筛板均匀受风冷却；

Three or four powerful centrifugal fans are used to cool the distiller's grains. The fans can be variable frequency speed regulation and power frequency operation. According to the outlet temperature, the computer will automatically control the start-up and stop of each fan and power frequency operation, and cooperate with two sets of slag turning rollers to turn the distiller's grains, It can reduce energy consumption and ensure the effect of distiller's grains spreading and airing. After optimization design, each fan's independent air chamber has a special structure, and the air supply is layered to ensure the sieve plate is evenly cooled by wind;

按配套工艺要求设计的加曲机可自动加曲，带称重传感器，自动调节电机频率控制加曲配比，可精确控制加曲比例；酒糟加曲后经扬片机翻拌后落入料斗（或接糟池），保证加曲后的充分混合；

The koji adding machine designed according to the matching process requirements can automatically add koji, with weighing sensor, automatically adjust the frequency of motor to control the ratio of adding starter, which can accurately control the proportion of adding starter; after adding starter, the distiller's grains will fall into the hopper (or distiller's pool) after being turned over by the tablet lifter to ensure the full mixing after adding starter;

不锈钢凉茬机 不锈钢数控凉茬机 酒厂设备

Stainless steel stubble cooling machine stainless steel CNC stubble cooling machine distillery equipment

摊晾机自带不锈钢操作平台，可随时观察机器工作情况并可随时人工介入调整。

The paver is equipped with stainless steel operation platform, which can observe the working condition of the machine at any time and adjust it manually at any time.

摊晾机出口处设计有不锈钢浆水喷淋管，方便酒糟摊晾后加浆水，将水管装有流量计加浆水均匀可控。

A stainless steel spray pipe is designed at the outlet of the machine, which is convenient for adding slurry water after the distiller's grains are aired. The water pipe is equipped with a flowmeter and the slurry adding water is uniform and controllable.

机器风室都设计有清理门，方便机器内部残渣清扫。

The air chamber of the machine is designed with cleaning door, which is convenient for cleaning the residue inside the machine.
